Sub2ApiPay

Language: 中文 | English (current)

Sub2ApiPay is a self-hosted recharge payment gateway built for the Sub2API platform. It supports Alipay, WeChat Pay (via EasyPay aggregator), and Stripe. Once a payment is confirmed, the system automatically calls the Sub2API management API to credit the user's balance — no manual intervention required.

---

Table of Contents

• Features
• Tech Stack
• Quick Start
• Environment Variables
• Deployment
• Sub2API Integration
• Admin Panel
• Payment Flow
• Development

---

Features

• Multiple Payment Methods — Alipay, WeChat Pay (EasyPay), Stripe credit card
• Auto Balance Credit — Automatically calls Sub2API after payment verification, fully hands-free
• Full Order Lifecycle — Auto-expiry, user cancellation, admin cancellation, refunds
• Limit Controls — Configurable per-transaction cap and daily cumulative cap per user
• Security — Token auth, MD5/Webhook signature verification, timing-safe comparison, full audit log
• Responsive UI — PC + mobile adaptive layout, dark mode support, iframe embed support
• Admin Panel — Order list (pagination/filtering), order details, retry recharge, refunds

---

Tech Stack

Category	Technology
Framework	Next.js 16 (App Router)
Language	TypeScript 5 + React 19
Styling	TailwindCSS 4
ORM	Prisma 7 (adapter-pg mode)
Database	PostgreSQL 16
Container	Docker + Docker Compose
Package Manager	pnpm

---

Quick Start

Using Docker Hub Image (Recommended)

No Node.js or pnpm required on the server — just Docker.

mkdir -p /opt/sub2apipay && cd /opt/sub2apipay

# Download Compose file and env template
curl -O https://raw.githubusercontent.com/touwaeriol/sub2apipay/main/docker-compose.hub.yml
curl -O https://raw.githubusercontent.com/touwaeriol/sub2apipay/main/.env.example
cp .env.example .env

# Fill in required environment variables
nano .env

# Start (includes bundled PostgreSQL)
docker compose -f docker-compose.hub.yml up -d

Build from Source

git clone https://github.com/touwaeriol/sub2apipay.git
cd sub2apipay
cp .env.example .env
nano .env
docker compose up -d --build

---

Environment Variables

See .env.example for the full template.

Core (Required)

Variable	Description
SUB2API_BASE_URL	Sub2API service URL, e.g. https://sub2api.com
SUB2API_ADMIN_API_KEY	Sub2API admin API key
ADMIN_TOKEN	Admin panel access token (use a strong random string)
NEXT_PUBLIC_APP_URL	Public URL of this service, e.g. https://pay.example.com

DATABASE_URL is automatically injected by Docker Compose when using the bundled database.

Payment Providers & Methods

Step 1: Declare which payment providers to load via PAYMENT_PROVIDERS (comma-separated):

# EasyPay only
PAYMENT_PROVIDERS=easypay
# Stripe only
PAYMENT_PROVIDERS=stripe
# Both
PAYMENT_PROVIDERS=easypay,stripe

Step 2: Control which channels are shown to users via ENABLED_PAYMENT_TYPES:

# EasyPay supports: alipay, wxpay  |  Stripe supports: stripe
ENABLED_PAYMENT_TYPES=alipay,wxpay

EasyPay (Alipay / WeChat Pay)

Any payment provider compatible with the EasyPay protocol can be used, such as ZPay (https://z-pay.cn/?uid=23808) (this link contains the author's referral code — feel free to remove it).

ZPay Registration QR Code

Disclaimer: Please evaluate the security, reliability, and compliance of any third-party payment provider on your own. This project does not endorse or guarantee any specific provider.

Variable	Description
EASY_PAY_PID	EasyPay merchant ID
EASY_PAY_PKEY	EasyPay merchant secret key
EASY_PAY_API_BASE	EasyPay API base URL
EASY_PAY_NOTIFY_URL	Async callback URL: ${NEXT_PUBLIC_APP_URL}/api/easy-pay/notify
EASY_PAY_RETURN_URL	Redirect URL after payment: ${NEXT_PUBLIC_APP_URL}/pay/result
EASY_PAY_CID_ALIPAY	Alipay channel ID (optional)
EASY_PAY_CID_WXPAY	WeChat Pay channel ID (optional)

Stripe

Variable	Description
STRIPE_SECRET_KEY	Stripe secret key (sk_live_...)
STRIPE_PUBLISHABLE_KEY	Stripe publishable key (pk_live_...)
STRIPE_WEBHOOK_SECRET	Stripe webhook signing secret (whsec_...)

Stripe webhook endpoint: ${NEXT_PUBLIC_APP_URL}/api/stripe/webhook Subscribe to: payment_intent.succeeded, payment_intent.payment_failed

Business Rules

Variable	Description	Default
MIN_RECHARGE_AMOUNT	Minimum amount per transaction (CNY)	1
MAX_RECHARGE_AMOUNT	Maximum amount per transaction (CNY)	1000
MAX_DAILY_RECHARGE_AMOUNT	Daily cumulative max per user (0 = unlimited)	10000
ORDER_TIMEOUT_MINUTES	Order expiry in minutes	5
PRODUCT_NAME	Product name shown on payment page	Sub2API Balance Recharge

UI Customization (Optional)

Display a support contact image and description on the right side of the payment page.

Variable	Description
PAY_HELP_IMAGE_URL	Help image URL — external URL or local path (see below)
PAY_HELP_TEXT	Help text; use \n for line breaks, e.g. Scan to add WeChat\nMon–Fri 9am–6pm

Two ways to provide the image:

• External URL (recommended — no Compose changes needed): any publicly accessible image link (CDN, OSS, image hosting).

  PAY_HELP_IMAGE_URL=https://cdn.example.com/help-qr.jpg


• Local file: place the image in ./uploads/ and reference it as /uploads/<filename>. The directory must be mounted in docker-compose.app.yml (included by default):

  volumes:
    - ./uploads:/app/public/uploads:ro


  PAY_HELP_IMAGE_URL=/uploads/help-qr.jpg


Clicking the help image opens it full-screen in the center of the screen.

Docker Compose Variables

Variable	Description	Default
APP_PORT	Host port mapping	3001
DB_PASSWORD	PostgreSQL password (bundled DB)	password (change in production)

---

Deployment

Option 1: Docker Hub Image + Bundled Database

Use docker-compose.hub.yml — the simplest deployment:

docker compose -f docker-compose.hub.yml up -d

Image: touwaeriol/sub2apipay:latest

Option 2: Docker Hub Image + External Database

For existing PostgreSQL instances (shared with other services):

1. Set DATABASE_URL in .env
2. Use docker-compose.app.yml (app only, no DB):

docker compose -f docker-compose.app.yml up -d

Option 3: Build from Source

For custom builds after modifications:

# On the build server
docker compose build
docker tag sub2apipay-app:latest touwaeriol/sub2apipay:latest
docker push touwaeriol/sub2apipay:latest

# On the deploy server
docker compose -f docker-compose.hub.yml pull
docker compose -f docker-compose.hub.yml up -d

Reverse Proxy

The default host port is 3001 (configurable via APP_PORT). Use Nginx or Caddy as a reverse proxy with HTTPS:

server {
    listen 443 ssl;
    server_name pay.example.com;

    location / {
        proxy_pass http://127.0.0.1:3001;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

Database Migrations

Migrations run automatically on container startup via prisma migrate deploy. To run manually:

docker compose exec app npx prisma migrate deploy

---

Sub2API Integration

The following page URLs can be configured in the Sub2API admin panel:

Page	URL	Description
Payment	https://pay.example.com/pay	User recharge entry
My Orders	https://pay.example.com/pay/orders	User views their own recharge history
Order Management	https://pay.example.com/admin	Sub2API admin only

Sub2API v0.1.88 and above will automatically append the following parameters — no manual query string needed:

Parameter	Description
user_id	Sub2API user ID
token	User login token (required to view order history)
theme	light (default) or dark
ui_mode	standalone (default) or embedded (for iframe)

---

Admin Panel

Access: https://pay.example.com/admin?token=YOUR_ADMIN_TOKEN

Feature	Description
Order List	Filter by status, paginate, choose 20/50/100 per page
Order Detail	View all fields and audit log timeline
Retry Recharge	Re-trigger recharge for paid-but-failed orders
Cancel Order	Force-cancel pending orders
Refund	Issue refund and deduct Sub2API balance

---

Payment Flow

User submits recharge amount
         │
         ▼
  Create Order (PENDING)
  ├─ Validate user status / pending order count / daily limit
  └─ Call payment provider to get payment link
         │
         ▼
  User completes payment
  ├─ EasyPay → QR code / H5 redirect
  └─ Stripe  → Payment Element (PaymentIntent)
         │
         ▼
  Payment callback (signature verified) → Order PAID
         │
         ▼
  Auto-call Sub2API recharge API
  ├─ Success → COMPLETED, balance credited automatically
  └─ Failure → FAILED (admin can retry)

---

Development

Requirements

• Node.js 22+
• pnpm
• PostgreSQL 16+

Local Setup

pnpm install
cp .env.example .env
# Edit .env with DATABASE_URL and other required values
pnpm prisma migrate dev
pnpm dev

Commands

pnpm dev                      # Dev server with hot reload
pnpm build                    # Production build
pnpm test                     # Run tests
pnpm typecheck                # TypeScript type check
pnpm lint                     # ESLint
pnpm format                   # Prettier format

pnpm prisma generate          # Generate Prisma client
pnpm prisma migrate dev       # Create and apply migration (dev)
pnpm prisma migrate deploy    # Apply migrations (production)
pnpm prisma studio            # Visual database browser

---

License

MIT
